| Temperature Control System |
| Hot lid temperature |
Air temperature~110°C |
| Constant pressure hot lid |
Compatible with consumables of different heights |
| module temperature |
0°C-100°C |
| Module humidity control principle |
Peltier effect, semiconductor refrigeration technology |
| heating/cooling rate |
Heating rate up to 6.1°C/s Cooling rate up to 5.0°C/s |
| temperature uniformity |
±0.1°C |
| Warm Seat Accurate Seat |
≤0.1°C |
| Gradient temperature width |
1°C~40°C |
| gradient temperature number |
12 columns |
| Special temperature setting function |
Support thermal gradient PCR experiment, long fragment PCR (Long PCR), landing PCR (Touch Down PCR) |
| Software function |
| analysis function |
Qualitative analysis, absolute quantitative analysis, relative quantitative analysis, endpoint fluorescence analysis, erasure curve analysis, SNP analysis, etc. |
| Report Customization |
Pre-store a variety of industry experiment report templates to support the clinical report management system |
| Rights management function |
The administrator account can limit the functions of "manually set threshold", "run setting", "run experiment", "analyze data" and other functions of the ordinary account, so as to realize the management of the instrument use authority of the general account |
| Resource sharing function |
After the instrument is connected to the PC, both parties can realize the synchronous sharing of experimental data through uploading, downloading and other operations |
| Transport lock function |
Automatic detection of remote input lock status. and make lock/unlock settings |
| fault management |
Intelligently judge the type of fault and perform fault management |
| LIS function |
Can export CSV, Excel, TXT and other formats Open data port, synchronous support for interconnection with LIS system |
| Other information |
| other information |
Win 7、Win10 |
| Interface Type |
1 Ethernet port, 1 front USB, 2 rear USB |
| Dimensions |
355mm x 475mm x 484mm(W x D x H) |
| weight |
30kg |
| input power |
AC220V,50Hz |
| power consumption |
900VA |
| working environment |
Temperature: 10C~30C, relative humidity: 20%~85% |
